TFGX1200 hydrogen tube furnace The processing tube is made of high-quality Ni-based superalloy which never cracks and breaks at flowing Hydrogen gas. One 3M hydrogen detector is included which will shut down the Hydrogen gas generator and gas inlet valve immediately once detecting hydrogen gas leaking.
Furnace shell
The shell is made of metal Q235 low-carbon steel, and the surface is electrostatically resistant and resistant to corrosion.
The solid double-layer metal frame is combined with the heat-insulating fan structure, and the furnace surface temperature is low
Horizontal use mode, upper opening structure, easy to operate
Refractory material
Multi-layer insulation design, composed of lightweight alumina ceramic fiber and high-quality insulation board backing, does not contain asbestos components, low heat loss and low energy consumption
Heating system
1、High-quality HRE spiral resistance wire
heating element is safely and firmly embedded on the inner surface of the
furnace, thermal radiation heating in the furnace cavity, which is
energy-saving and efficient, long service life.
2、Ring heating by resistance wire to achieve good uniformity in the furnace.
Temperature Control Panel
1、Advanced controllers that meet complex
process requirements.
2、Programmable 30 program segments to realize automatic curve temperature
control.
3、Over temperature and fault alarm, automatic safety protection.
Rotary System
1、The furnace tube adopts a gear transmission
electric drive structure to rotate 360°, 12-20 rpm rotating speed, and the
material is heated evenly in the furnace tube.
2、The furnace body can be tilted by electric drive, the tilt angle can be
adjusted, and the material can enter and exit more smoothly.
3、With 304 stainless steel sealing flange, to obtain vacuum or atmosphere
environment in the furnace tube.
4、High-quality quartz tubes, metal or alumina ceramic tubes can also be
selected to adapt different working conditions.
Model
TFGX-60-12
TFGX-100-12
TFGX-150-12
TFGX-200-12
Reactor Quartz Tube
Φ60×1200mm
Φ100×1200mm
Φ150×1500mm
Φ200×1500mm
Heating Zone Length
440mm
440mm
600mm
600mm
Max Temp
1200℃
Continue Temp
1100℃
Heating Element
High quality Alloy Resistance Wire（HRE）
Chamber Material
Polycrystalline inorganic alumina ceramic fiber materials
Temp Precision
±1℃
Thermocouple
B-type national standard platinum rhodium thermocouple
Temp Controller
Intelligent
microcomputer PID temperature control instrument, SSR control, PID parameter
self-tuning function; programmable 30 program segments, program temperature
rise, program heat preservation, program cooling
Heating Rate
1-20℃/min free
adjustment
Furnace Structure
Furnace temperature control integrated structure; double-layer
shell, air circulation and heat insulation
Equipment Protection
Modular
control, sound and light alarm signal will be sent out for over temperature
and broken coupler in the working process, and the protection action will be
completed automatically
Safety Protection
The
equipment is equipped with a circuit breaker, which will automatically pop
open in case of short circuit leakage, which can protect the safety of
equipment and operators
Furnace Shell
High-quality
cold-rolled steel plate CNC machine tool blanking processing, after welding,
grinding, polishing, phosphating, pickling, surface electrostatic spraying
plastic powder
The standard configuration
1.
1 furnace body 2. 1 temperature controller 3. Power cord 3 meters 4. 1
thermocouple 5. 1 manual6. One furnace hook 7. One pair of high temperature
gloves 8. Two pipe plugs 9. One set of sealing flange
